It is weaving machine used to weave various natural fibers such as cotton, wool, silk, and flax, as well as man-made fibers, and synthetic fibers. The GA731-II series rapier loom is a reflection of our outstanding expertise and decades of manufacturing experience. To allow for multiple functionalities and optimized cost-performance ratio, the loom with mature technology and stable functioning has been devised. It is suitable for fabricating natural, man-made, and synthetic fibers.
Nominal reed width: 190, 210, 230, 260, 280 cm.
Weaving Capacity: Cotton or synthetic fiber yarn 1.2Ne-120Ne, Slub yarn or worsted yarn 1.5Nm-100Nm. The RFRL20 series rapier loom utilizes the relutance motor to enable fast start and low energy consumption. Thanks to the stepless speed control, the machine is able to accomplish speed change automatically throughout the weaving process while operating at rotational speeds ranging from 380 to 450 rounds per minute.
It is used for weaving cotton or man-made fiber, slub yarn or worsted yarn and filament.
It is with jacquard shedding system. The RFRL31 energy efficient type high speed rapier loom inherites the benificial features of previous RFRL30 series by incorpoarting the switched reluctance drive system into its motor. This motor assembly delivers high power factor which is desirable for energy saving.
It is for weaving terry towels as well as French Terry cloth.
Loop pile height 0-24mm. The RFTL60 high speed terry rapier loom can reach a top rotational speed of 550 rounds per minute while delivering maximum weaving speeds ranging between 400 and 450 rounds per minute. This type of weaving machine employs the moveable reed motion and electronic control for pile formation. The maximum distance that a single thread of weft can travel is 24mm.
The loom machine is for weaving natural fibers such as cotton, wool, silk, and flax, as well as rayon. The weft insertion and beat-up motion is created by the movement of conjugate cams. In the weft insertion process, a flexible rapier with steel tape is used to carry the weft yarn through the middle of the shed. It never comes so close to the weft yarn or warp yarn as to cause damage to them.
The air jet loom is to weave natural, synthetic, rayon and blended fiber yarns into apparel, upholstery, and industrial fabrics. The weaving guidance system monitors the operating status of the loom and guides it to adopt the most suitable process for weaving quality fabric. Based on the air jet loom condition and weave specifications, the system can automatically set appropriate parameters.
